Hot Aisle Containment

What is Hot Aisle Containment? When is Hot Aisle Containment the Appropriate Solution?


WHAT IS HOT AISLE CONTAINMENT

Hot aisle containment consists of a physical barrier that guides hot exhaust airflow back to the AC return.

Hot aisle containment (HAC) takes advantage of the natural properties of warm air rising. The HAC system directs the upward airflow to an AC return system such as a drop-ceiling void. The HAC can increase cooling efficiency by 30% or more. Several cascading adjustments include temperature and RH set points, lower AC fan speeds, and an increased chilled water set point.

COOLING EFFICIENCY SAVES COSTS

Hot Aisle Containment can double the cooling capacity

Hot aisle containment (HAC) increases the effectiveness of your data center cooling. HAC keeps hot exhaust air emitted from server racks separated so that it returns to the AC coil both hot and dry (low relative humidity) increasing the AC’s cooling capacity. Through HAC, the hot air is given a separate pathway back to the AC intake without mixing with the cold air. In some cases, by containing the hot air and having it hit the AC coil at the hottest temperature possible, it can double the cooling tonnage.

Hot Aisle Containment can double the CRAC/CRAH cooling capacity.

KEY BENEFITS OF HOT AISLE CONTAINMENT:

  • Separates supply and return airflow which provides a uniform and predictable to both IT temperature and AC equipment.
  • Eliminates hot and cold air mixing
  • Works in both a raised floor and slab environments
  • Increases cooling capacity
  • Saves energy and improves data center cooling efficiency

SEEING IS BELIEVING — PROJECT EXAMPLES

Hot Aisle Containment Solutions

A variety of hot aisle containment configurations are shown below. These are actual customer projects, custom designed for their unique challenges.

Hot Aisle Containment

Non-Raised Floor Example

Based upon a non-raised floor, this hot aisle containment project comprises dual hinged doors, and the Polar Cap 2 retractable roof system.

Hot Aisle Containment

Raised Floor Example 1

Hot aisle containment with raised flooring, dual sliding doors, and vinyl Rack Hat between the ceiling and cabinets.

Hot Aisle Containment

Raised Floor Example 2

Hot aisle containment through raised flooring, vinyl strip doors, and vinyl Rack Hat of varying height to provide containment in gaps between the ceiling, cabinets, and potential missing cabinets.

Hot Aisle Containment

Raised Floor Example 3

Hot aisle containment system with raised flooring, dual sliding doors, and rigid wall panels.

Hot Aisle Containment

Raised Floor Example 4

Hot aisle containment system with raised flooring, dual sliding doors, and rigid wall panels.

LET US BE YOUR GUIDE

Thoroughly understand your Options

The decision affects the longevity of your facility and your bottom line

Intelligent data center solutions begin with understanding your unique situation. Let us educate you in the latest insights and options, so you can make informed and confident decisions for your facility.
